meanwell NPF-120D (D Tİpi)

Teklif İste

NPF-120D (D Tİpi)

Ürün Kodu Güç VDC Amp 3 Dim Tol Verim IP Boyut NPF-120D-12 120W 12V 10.00A 1-10Vdc,PWM,Resistance %4 %88 IP67 191x63x38mm NPF-120D-15 120W 15V 8.00A 1-10Vdc,PWM,Resistance %4 %88 IP30 191x63x38mm NPF-120D-20 120W 20V 6.00A 1-10Vdc,PWM,Resistance %4 %89 IP30 191x63x38mm NPF-120D-24 120W 24V 5.00A 1-10Vdc,PWM,Resistance %4 %89 IP30 191x63x38mm NPF-120D-30 120W 30V 4.00A 1-10Vdc,PWM,Resistance %4 %89 IP30 191x63x38mm NPF-120D-36 120W 36V 3.40A 1-10Vdc,PWM,Resistance %4 %90 IP30 191x63x38mm NPF-120D-42 120W 42V 2.90A 1-10Vdc,PWM,Resistance %4 %90 IP30 191x63x38mm NPF-120D-48 120W 48V 2.50A 1-10Vdc,PWM,Resistance %4 %90 IP30 191x63x38mm NPF-120D-54 120W 54V 2.30A 1-10Vdc,PWM,Resistance %4 %90 IP30 191x63x38mm

Ürün Kodu: Kategori: led-guc-kaynaklari

Açıklama
Teknik Özellikler

Ürün Açıklaması

Ürün Kodu	Güç	VDC	Amp	3 Dim	Tol	Verim	IP	Boyut
NPF-120D-12	120W	12V	10.00A	1-10Vdc,PWM,Resistance	%4	%88	IP67	191x63x38mm
NPF-120D-15	120W	15V	8.00A	1-10Vdc,PWM,Resistance	%4	%88	IP30	191x63x38mm
NPF-120D-20	120W	20V	6.00A	1-10Vdc,PWM,Resistance	%4	%89	IP30	191x63x38mm
NPF-120D-24	120W	24V	5.00A	1-10Vdc,PWM,Resistance	%4	%89	IP30	191x63x38mm
NPF-120D-30	120W	30V	4.00A	1-10Vdc,PWM,Resistance	%4	%89	IP30	191x63x38mm
NPF-120D-36	120W	36V	3.40A	1-10Vdc,PWM,Resistance	%4	%90	IP30	191x63x38mm
NPF-120D-42	120W	42V	2.90A	1-10Vdc,PWM,Resistance	%4	%90	IP30	191x63x38mm
NPF-120D-48	120W	48V	2.50A	1-10Vdc,PWM,Resistance	%4	%90	IP30	191x63x38mm
NPF-120D-54	120W	54V	2.30A	1-10Vdc,PWM,Resistance	%4	%90	IP30	191x63x38mm
