meanwell NPF-90D (D Tİpi)

Teklif İste

NPF-90D (D Tİpi)

Ürün Kodu Güç VDC Amp 3 Dim Tol Verim IP Boyut NPF-90D-12 90W 12V 7.50A 1-10Vdc,PWM,Resistance %4 %88 IP67 171x63x38mm NPF-90D-15 90W 15V 6.00A 1-10Vdc,PWM,Resistance %4 %89 IP30 171x63x38mm NPF-90D-20 90W 20V 4.50A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-24 90W 24V 3.75A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-30 90W 30V 3.00A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-36 90W 36V 2.50A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-42 90W 42V 2.15A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-48 90W 48V 1.88A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm NPF-90D-54 90W 54V 1.67A 1-10Vdc,PWM,Resistance %4 %90 IP30 171x63x38mm

Ürün Kodu: Kategori: led-guc-kaynaklari

Açıklama
Teknik Özellikler

Ürün Açıklaması

Ürün Kodu	Güç	VDC	Amp	3 Dim	Tol	Verim	IP	Boyut
NPF-90D-12	90W	12V	7.50A	1-10Vdc,PWM,Resistance	%4	%88	IP67	171x63x38mm
NPF-90D-15	90W	15V	6.00A	1-10Vdc,PWM,Resistance	%4	%89	IP30	171x63x38mm
NPF-90D-20	90W	20V	4.50A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-24	90W	24V	3.75A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-30	90W	30V	3.00A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-36	90W	36V	2.50A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-42	90W	42V	2.15A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-48	90W	48V	1.88A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
NPF-90D-54	90W	54V	1.67A	1-10Vdc,PWM,Resistance	%4	%90	IP30	171x63x38mm
